CDP Public Cloud reference network architecture for AWS

This topic includes a conceptual overview of the CDP Public Cloud network architecture for AWS, its use cases, and personas who should be using it

Overview

CDP Public Cloud allows customers to set up cloud Data Lakes and compute workloads in their cloud accounts on AWS, Azure, and Google Cloud. It maps a cloud account to a concept called the environment into which all compute workload clusters (Data Hubs) and data services (such as Cloudera Data Engineering (CDE), Cloudera Data Warehouse (CDW), Cloudera Machine Learning (CML), Cloudera Operational Database (COD), Cloudera DataFlow (CDF)) are launched. For these Data Lakes, compute workload clusters, and data services to function correctly, several elements of the cloud architecture need to be configured appropriately: access permissions, networking setup, cloud storage and so on. Broadly, these elements can be configured in one of two ways:

  • CDP can set up these elements for the customer

    Usually, this model helps to set up a working environment quickly and try out CDP. However, many enterprise customers prefer or even mandate specific configurations of a cloud environment for Infosec or compliance reasons. Setting up elements such as networking and cloud storage requires prior approvals and they would generally not prefer, or even actively prevent, a third party vendor like Cloudera to set up these elements automatically.

  • CDP can work with pre-created elements provided by the customer

    In this model, the flow for creating the cloud Data Lakes accepts pre-created configurations of the cloud environment and launches workloads within those boundaries. This model is clearly more aligned with enterprise requirements. However, it brings with it the risk that the configuration might not necessarily play well with CDP requirements. As a result, customers might face issues launching CDP workloads and the turnaround time to get to a working environment might be much longer and involve many tedious interactions between Cloudera and the customer cloud teams.

From our experience in working with several enterprise customers, the most complicated element of the cloud environment setup is the cloud network configuration. The purpose of this document is to clearly articulate the networking requirements needed for setting up a functional CDP Public Cloud environment into which the Data Lakes and compute workloads of different types can be launched. It attempts to establish the different points of access to these workloads and establishes how the given architecture helps to accomplish this access.

Along with this document, you can use the cloudera-deploy tool to automatically set up a model of this reference architecture, which can then be reviewed for security and compliance purposes.

Use cases

CDP Public Cloud allows customers to process data in the cloud storage under a secure and governed Data Lake using different types of compute workloads that are provisioned via Data Hub or data services. Typically the lifecycle of these workloads is as follows:

  • A CDP environment is set up by a CDP admin using their cloud account. This sets up a cloud Data Lake cluster and FreeIPA cluster with security and governance services and an identity provider for this environment. The CDP admin may need to work with a cloud administrator to create all the cloud provider resources (including networking resources) that are required by CDP.
  • Then one or more compute workload clusters can be launched, linked to the Data Lake. Each of these workload clusters typically serves a specific purpose such as data ingestion, analytics, machine learning and so on.
  • These compute workload clusters are accessed by data consumers like data engineers, analysts or scientists. This is the core purpose of using CDP on the public cloud.
  • These compute workload clusters can be long-running or ephemeral, depending on the customer needs.

There are two types of users for CDP who interact with the product for different purposes:

  • CDP admins - These persons are usually concerned with the launch and maintenance of the cloud environment, and the Data Lake, Data Hubs, FreeIPA, and CDP data services running inside the environment. They use a Management Console running in the Cloudera AWS account to perform these operations of managing the environment.
  • Data consumers - These are the data scientists, data analysts, and data engineers who use the Data Hubs and data services to process data. They mostly interact directly with the compute workloads (Data Hubs and data services) running in their cloud account. They could access these either from their corporate networks (typically through a VPN) or other cloud networks their corporate owns.

These two types of users and their interaction with CDP are represented in the following diagram:
