Secure inbound communication

The Cloudera Control Plane communicates with workload environments for various command and control purposes. These connections currently go over the Internet to the workload environment hosts. Consequently, Cloudera deploys workloads into public (Internet routable) subnets.

To operate in public subnets, Cloudera secures in-bound communication to the listening ports using TLS encryption. Connections are authenticated using environment- or cluster-specific credentials that Cloudera manages internally. As appropriate, administrators can further secure listening ports by authenticating IP addresses and/or ports:

  • Identifying authentic connections: Use security group rules to ensure inbound connections originate from the set of stable IP addresses that belong to your organization.
  • Identifying authentic ports: Inbound connections take place on an identifiable set of ports, which can be used to additionally narrow the allowlist.

In addition to the Cloudera management traffic, your organization's use cases may specify connecting to the workload hosts over the Internet. These communications may involve different endpoints, protocols, ports, and credentials than Cloudera management traffic.

Endpoints fall into four categories today, associated with our shared Environment services on the Data Lake and on Cloudera Data Hub, Cloudera Data Warehouse, and Cloudera AI workloads. The following sections enumerate the communications for each of those categories.

Data Lake communication endpoints

In-bound communication for shared services support Cloudera management of FreeIPA and Data Lake services.

Each Environment contains a deployment of FreeIPA and a Data Lake cluster that support the following security and governance activities:

Free IPA identity and security services
  • LDAP: User Directory
  • Kerberos KDC: Manages a Kerberos Realm for the Environment
  • DNS: Provides internal resolution of workload hostnames
  • Certificate Authority: Issues TLS certificates for internal use, and for the in-bound Cloudera control connections
Data Lake cluster services
  • Hive Metastore: Tabular metadata storage
  • Ranger: Security policies and audit trail
  • Atlas: Data lineage, tagging, analytics
  • ID Broker: Mapping of Cloudera identities to cloud provider identities
  • Knox: A proxy gateway for access to cluster services
  • Cloudera Manager: Local management for the data lake services


Communication to the Cloudera Control Plane includes the following:

Free IPA identity and security services

  • User and Group synchronization

  • Service Principal management

  • Retrieving the CA root certificate

Data Lake cluster services
  • Core lifecycle management operations (sent directly between Cloudera and Cloudera Manager to include the Knox proxy as one of the managed entities; shown as a dashed line in the picture)
  • Communication (via Knox proxy)
    • General Cloudera Manager operations
    • Ranger operations to manage repositories for workloads
    • ID Broker mappings (updated via Cloudera Manager)
    • Cloudera Data Catalog communicates with Atlas and Ranger to surface information

Cloudera Data Hub communication endpoints

Cloudera Data Hub clusters are built on the same underlying technology as the Data Lake cluster and so present a similar connectivity profile.



Communication to the Cloudera Control Plane includes the following:

Free IPA identity and security services

  • User and Group synchronization

  • Service Principal management

  • Retrieving the CA root certificate

Data Lake cluster services
  • Core lifecycle management operations (sent directly between Cloudera and Cloudera Manager because the Knox proxy is one of the managed entities; shown as a dashed line in the previous picture)
  • Communication (via Knox proxy)
    • General Cloudera Manager operations
    • Service-specific communication depending on the specific Cloudera Data Hub cluster in question

Cloudera Data Warehouse communication endpoints

The Cloudera Data Warehouse service operates significantly differently from Cloudera Data Hub, as it runs on top of a Kubernetes cluster and does not include a Cloudera Manager instance.



Primary command and control communication goes to the Kubernetes API server. This endpoint is specific to a particular Kubernetes cluster, but it is provisioned by the cloud provider outside of the customer VPC. Whether or not it is Internet-facing is independent of the VPC configuration. The Cloudera Data Warehouse service doesn’t make connections to endpoints in the cluster.

Cloudera AI communication endpoints

In terms of communication, a Cloudera AI Workbench looks very similar to a Cloudera Data Warehouse workspace in that it is also a Kubernetes cluster, although the contents differ.



Primary command and control communication goes to the Kubernetes API server. This endpoint is specific to a particular Kubernetes cluster, but it is provisioned by the cloud provider outside of the customer VPC. Whether or not it is Internet-facing is independent of the VPC configuration. The Cloudera AI service doesn’t make connections to endpoints in the cluster.
